ইস্পাত বার কাটা এবং মেশিন সোজা

No.

Item

Specification

1

Air source

MAX7.2kg∕cm²(0.1mpa)

2

Max cutting capacity

13T

3

Iinput voltage

three phase,four wire,AC380V±5%,50Hz

4

Cutting tolerance

Cutting tolerance allow±1mm

5

Hauling maximum speed

38M/min

6

Mmachine size

L×W×H=17000×700×2100

UNIT(mm)

7

Mmachine weight

2T

8

Ssame specification devide

devide left hand(model:z)and right hand(model:Y)two operations

9

Cutting PC bar diameter

ø7.1,ø9.0,ø10.7,ø12.6

10

Operation knife and fixed knife specification

ø7.1,ø9.0,ø10.7,ø12.6
